1323RE (4389RE)

Rough Terrain Scissor Lifts

Working Height

15.1m

Platform Capacity

680kg

Gradeability

40%

Download Brochures

SPECIFICATIONS
Standard/Optional
APPLICATIONS

DIMENSIONS

Max Working Height

15.1m (49'6.5")
[A] Max Platform Height

13.1m (42'11.7")
[B] Max Horizontal Extension

1.5m/1.2m (4'11.1"/3'11.2" )
[C] Length-Stowed (Outriggers/Without Outriggers)

4.88m (16')
[D] Width-Stowed

2.28m (7'5.7")
Height -stowed (Rail Folded)

2.2 m (7'2.6")
[E] Height -stowed(Rail Unfolded)

2.96 m (9'8.5")
[F] Wheelbase

2.84m (9'3.8")
Ground Clearance

0.36m (1'2.2")
Platform Dimensions(LxWxH)

6.5m Platform: 3.96m×1.82m×1.1m(13×6'×3'7") 7.4m Platform: 4.84m×1.82m×1.1m(15'10.6''×6'×3'7")

PRODUCTIVITY

Platform Allowable Occupants(Indoor)

7 Persons
Platform Allowable Occupants(0utdoor)

7 Persons
Platform Capacity

680kg (1,499lbs)
Drive Speed-Stowed

5.3km/h (3.3mph)
Drive Speed-Raised

1.1km/h (0.68mph)
Elevation Time(Unloaded)

50s~60s
Descent Time(Unloaded)

34s~44s
Gradeability

0.4
Turning Radius(Inside/Outside)

2.2m/5.3m (7'2.6"/17'4.7")
Tilt Rating(Front to Back)

3°
Tilt Rating(Side to Side, Outrigger Tele-ln/Tele-Out)

2 °/0.5 °
Max Outrigger Leveling(Front to Back)

7°
Max Outrigger Leveling(Side to Side)

12°
Tyres-solid

33x12-20/solid

POWER

Power Source

48 V,480 Ah(Lead-acid battery) / 51.2V,500Ah(Lithium battery)
Drive Mode

48 VDC
Fuel Tank Capacity - Diesel

-
Hydraulic System Capacity

110L (24 gal(UK) / 29 gal(US))

WEIGHT

Weight(Outriggers/Without Outriggers)

7,970 kg(17,570 lbs) / 8,360kg(18,430lbs)
Standards Compliance

GB/CE/ANSI/EAC

Download Brochures

Standard features

4WDX2WS
Forklift pockets and lifting points
Proportional control
Manual storage box
Maintenance-free battery
Emergency lowering system
Emergency stop

Optional features

Non-marking tires
Industrial power device on platform
7.4m platform
